MAI INTERNATIONAL

GmbH

SPARE PARTS "FIGURE G"

Pos. P/N Description

1 151066 Connector angular 32A 5 poles 400V

2 101188 Socket 32A 4pole 400V

2 100025 Socket 16 A 5poles 400V

3 151728 Indicator light lens assembly M22-L-R red

4 151594 Selector switch 3 Stellungen M22-WRK3

5 150961 Main switch P1-32/EA/SVB 32A

5.01 w/o Fig. 153262 Mainswitch P3-63/EA/SVB 6-7,5kW Japan

6 152051 Illuminated pressure switch white M22-DL-W

6 151593 Protection cap M22-T-D

7 152293 Illuminated push button M22-DL-G

7 151593 Protection cap M22-T-D

8 151591 Push button red M22-D-R

8 151593 Protection cap M22-T-D

9 151592 Push button yellow M22-D-Y

9 151593 Protection cap M22-T-D

10 151698 Selector switch M22-WRK

11 100472 Socket 16A 3 poles 50V

12 101572 Hour meter BA632,2 42V / 50 Hz
