Maico MA 42 Service Manual

Service Manual MA 42
D-0125965 Rev. D
8
18/05/2022
Table 6 STIM/TALK Key and STIM/Monitor Key
Key
Select
Function
STIM
Talk
Quick Select
STIM: to switch between Presenter and Interrupter mode.
Advanced
Select
Talk: to open the Communication widget (Figure 5)
Figure 4
Talk Forward: Allows tester to provide instruction to the
patient while the headphones are in place.
Increase/decrease the volume by using the Control dial
and the key. The lighted bar/VU meter allows the
examiner to monitor their voice for optimal sound quality.
When speaking, 0 is the optimal level.
Talk Back: Allows you to hear the patient through the
internal speaker or monitor headset via an optional talk
back microphone. Increase/decrease the volume or set
the function off by using the Control dial and the key.
The volume dial on the monitor headset must also be
controlled for optimal volume.
Press STIM to close the widget again.
STIM
Monitor
Quick Select
STIM: to switch between Presenter and Interrupter mode.
Advanced
Select
Tone Test:
Monitor: to open the Monitor widget (Figure 6).
Figure 5
Allows you to hear the Tone and Noise stimuli through the
internal speaker or monitor headset. Increase/decrease the
volume or set the function off by using the Control dial and
the Key. The volume dial on the monitor headset must
also be controlled for optimal volume.
