REFLEX CALIBRATION STANDARDS AND SPECTRAL PROPERTIES
General Specifications for stimulus and audiometer signals are made to follow
IEC 60645-5/ANSI S3.39.
Ipsilateral Earphone:
Pure Tone:
MAICO Standard Values
Contralateral
Earphone:
Pure Tone:
ISO 389-2 for IP 30
RadioEar Standard Values for DD45 C
Ipsilateral Earphone:
Broad-band
noise (BBN):
MAICO Standard Values
Contralateral
Earphone:
Broad-band
noise (BBN):
RadioEar Standard Values
Ipsi- and
Contralateral
Earphone:
Spectral
Properties
As “Broad-band noise” specified in IEC 60645-5,
but with 500 Hz as lower cut-off frequency.
General
about levels:
The actual sound pressure level at the
eardrum will depend on the volume of the ear.
The risk of artifacts at higher stimulus levels in reflex measurements are minor and
will not activate the reflex detection system.
AUDIOMETRY
Air Conduction:
DD45:
RadioEar Standard Values
IP30:
ISO 389-2, ANSI S3.6
DD450:
RadioEar Standard Values
Bone
Conduction:
B71:
B81:
ISO 389-3, ANSI S3.6
ISO 389-3, ANSI S3.6
Placement:
Mastoid
Effective masking:
ISO 389-4, ANSI S3.6
Transducers –
Headband tension:
DD45:
Headband Static Force 4.5 N ± 0.5 N
DD450:
Headband Static Force 10.0 N ± 0.5 N
B71/B81:
Headband Static Force 5.4 N ± 0.5 N
Patient Response
switch:
One push button
Patient
communication:
Talk Forward
Talk Back
Inputs:
Tone, Warble Tone ± 5 %, 5 Hz (true sine wave frequency
modulation).
Outputs:
Left, Right, Bone L+R
Accuracy:
Frequency ± 2 %, Level ± 3 dB
Stimuli
Warble Tone:
5 Hz sine ± 5 % modulation
Pulse Tone:
Pulse Length: 250 ms or 500 ms
Masking:
Narrow band noise: IEC 60645-1, 5/12 Octave filter with the
same centre frequency resolution as pure Tone. Synchronous
masking: Locks channel 2 attenuator to channel 1 attenuator
Alternative: White band noise.
Presentation:
Presenter or Interrupter. Single, Pulse or Warble.
Level:
AC: -10 dB HL to 120 dB HL, BC: -10 dB HL to 80 dB HL
Available Level Steps are 1 dB or 5 dB.
Extended range function: Warning displayed when 100 dB HL
reached. Extended range is accessed automatically.
Frequency
range:
AC: 125 Hz to 8000 Hz, BC: 250 Hz to 8000 Hz. Frequencies
can be freely deselected (except 1000 Hz).
