Guidance and Manufacturer’s Declaration - Electromagnetic Immunity
The touchTymp is intended for use in the electromagnetic environment specified below. The customer or the user of the touchTymp
should assure that it is used in such an environment.
Immunity Test
IEC 60601 Test level
Compliance
Electromagnetic environment - guidance
Electrostatic
Discharge (ESD)
IEC 61000-4-2
+8 kV contact
+15 kV air
+8 kV contact
+15 kV air
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be
greater than 30%.
Electrical fast
transient/burst
IEC61000-4-4
+2 kV for power supply lines
+1 kV for input/output lines
+2 kV for power supply lines
+1 kV for input/output lines
Mains power quality should be that of a
typical commercial or residential environment.
Surge
IEC 61000-4-5
+1 kV differential mode
+2 kV common mode
+1 kV differential mode
+2 kV common mode
Mains power quality should be that of a
typical commercial or residential environment.
Voltage dips,
short
interruptions and
voltage variations
on power supply
lines
IEC 61000-4-11
< 5% UT (>95% dip in UT)
for 0.5 cycle
40% UT (60% dip in UT)
for 5 cycles
70% UT (30% dip in UT)
for 25 cycles
<5% UT (>95% dip in UT)
for 5 sec
< 5% UT (>95% dip in UT)
for 0.5 cycle
40% UT (60% dip in UT)
for 5 cycles
70% UT (30% dip in UT)
for 25 cycles
<5% UT
for 5 sec
Mains power quality should be that of a
typical commercial or residential environment.
If the user of the touchTymp requires
continued operation during power mains
interruptions, it is recommended that the
touchTymp be powered from an
uninterruptable power supply or its battery.
Power frequency
(50/60 Hz)
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or residential environment.
Note: UT is the A.C. mains voltage prior to application of the test level.
