8 ENGLISH
Adjusting arm inclination
angle to make a comfortable working position.
Loosen the lock lever by raising it. Pivot the arm to the
Fig.3: 1. Lock lever 2. Arm
installed with the optional arms that are designed for
the corresponding belt widths. Loosen the screw that
secures the arm and replace the standard-equipped
Fig.4: 1. Screw 2. Arm
WARNING:
the tool from unintended starting. NEVER use
CAUTION: -
Operating a tool
with a switch that does not actuate properly can lead
NOTICE: -
NOTICE:
To prevent the switch trigger from being accidentally
lever ( ) from the A side to unlock the switch trigger,
and ( ) from the B side to lock in.
Fig.5: 1.
To start the tool, pull the switch trigger. Release the
switch trigger to stop.
For continuous operation, pull the switch trigger and
then push in the lock button. To stop the tool from the
locked switch position, pull the switch trigger fully, and
then release it.
Fig.6: 1. Lock-on button 2. Switch trigger
CAUTION: Do not look in the light or see the
through an angle of 60°. Pull the switch trigger to turn
approximately 10 seconds after releasing the switch
trigger.
Fig.7: 1. Lamp
NOTE:
for one minute. In this case, cool down the tool before
operating again.
NOTE:
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
1,700 m per minute (1,970 - 5,600 ft/min) by turning the
to 5.
Higher speed is obtained when the dial is turned in the
direction of number 5; lower speed is obtained when it
is turned in the direction of number 1. Select the proper
speed for the workpiece to be sanded.
CAUTION:
Fig.8: 1.
ASSEMBLY
CAUTION:
belt
Pull the cam lever back to release the tension in the
belt, and remove the belt.
To install the belt, place one side of the belt over the
-
ley, and then set the cam lever to the original position.
Fig.9: 1. Cam lever 2. Abrasive belt 3. Rear pulley
4. Front pulley
