11 ENGLISH
Changing the impact force
You can change the impact force in four steps: 4 (max), 3 (hard), 2 (medium), and 1 (soft).
This allows a tightening suitable to the work.
Thelevelofimpactforcechangeseverytimeyoupressthebutton or the quick mode-switching button.
Youcanchangetheimpactforcewithinapproximatelyoneminuteafterreleasingtheswitchtrigger.
NOTE:Youcanextendthetimetochangetheimpactforceapproximatelyoneminuteifyoupressthebut-
ton
, , or the quick mode-switching button.
1
►1. Button
Application mode
(Impact force grade
displayed on panel)
Maximum blows Purpose Example of application
4 (Max)
3,800 min
-1
(/min) Tightening with the maximum force
and speed.
Driving screws to underwork materi-
als, tightening long screws or bolts.
3 (Hard)
3,600 min
-1
(/min) Tightening with less force and speed
than Max mode (easier to control than
Max mode).
Driving screws to underwork materi-
als, tightening bolts.
2 (Medium)
2,600 min
-1
(/min) Tighteningwhenagoodnishingis
needed.
Drivingscrewstonishingboardsor
plaster boards.
1 (Soft)
1,100 min
-1
(/min) Tightening with less force to avoid
screw thread breakage.
Tightening sash screws or small
screws such as M6.
: The lamp is on.
NOTE: When none of the lamp on the panel is lit, pull the switch trigger once before pressing the button
or the
quick mode-switching button.
NOTE:Alllampsontheswitchpanelgooutwhenthetoolisturnedo󰀨tosavethebatterypower.Theimpactforce
gradecanbecheckedbypullingtheswitchtriggertotheextentthatthetooldoesnotoperate.
