Makita HP457D User Manual

8 ENGLISH
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge.Failuretoholdthetoolandthebattery
cartridgermlymaycausethemtoslipo󰀨yourhands
andresultindamagetothetoolandbatterycartridge
andapersonalinjury.
►Fig.1: 1. Red indicator 2. Button 3. Battery cartridge
Toremovethebatterycartridge,slideitfromthetool
whileslidingthebuttononthefrontofthecartridge.
Toinstallthebatterycartridge,alignthetongueonthe
batterycartridgewiththegrooveinthehousingandslip
it into place. Insert it all the way until it locks in place
withalittleclick.Ifyoucanseetheredindicatoras
showninthegure,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen.Ifnot,
itmayaccidentallyfalloutofthetool,causinginjuryto
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
Battery protection system
Thebatterycartridgeisequippedwiththeprotection
system,whichautomaticallycutso󰀨theoutputpower
foritslongservicelife.
Thetoolstopsduringoperationwhenthetooland/or
batteryareplacedunderthefollowingsituation.Thisis
causedbytheactivationofprotectionsystemanddoes
notshowthetooltrouble.
• Whenthetoolisoverloaded:
At this time, release the switch trigger, remove the
batterycartridgeandremovecausesofoverload
and then pull the switch trigger again to restart.
• Whenbatterycellsgethot:
Ifanyoperationoftheswitchtrigger,themotorwill
remainstopped.Atthistime,stopuseofthetool
andcoolthebatterycartridge.
• Whentheremainingbatterycapacitygetslow:
Ifyoupulltheswitchtrigger,themotorrunsagain
butstopssoon.Inthiscase,topreventoverdis-
charge,removethebatterycartridgefromthetool
and charge it.
Switch action
►Fig.2: 1. Switch trigger
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the “OFF” position when released.
Tostartthetool,simplypulltheswitchtrigger.Tool
speedisincreasedbyincreasingpressureontheswitch
trigger. Release the switch trigger to stop.
Reversing switch action
►Fig.3: 1. Reversing switch lever
CAUTION: Always check the direction of
rotation before operation.
CAUTION: Use the reversing switch only after
the tool comes to a complete stop. Changing the
directionofrotationbeforethetoolstopsmaydam-
age the tool.
CAUTION: When not operating the tool,
always set the reversing switch lever to the neu-
tral position.
Thistoolhasareversingswitchtochangethedirection
ofrotation.Depressthereversingswitchleverfromthe
AsideforclockwiserotationorfromtheBsideforcoun-
terclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion,theswitchtriggercannotbepulled.

Makita HP457D Specifications

General

Voltage	18V
Chuck Capacity	13 mm
Weight	1.7 kg
Power Source	Cordless
Max Drilling Capacity in Steel	13 mm
Max Drilling Capacity in Wood	36 mm
Max Drilling Capacity in Masonry	13 mm
Torque Settings	16 + Drill
Max Fastening Torque (Hard)	42 Nm
Type	Combi Drill
No Load Speed	0-400 / 0-1, 400 RPM
Impact Rate	0 - 6000 / 0 - 21000 ipm
