Makita HR4010C User Manual

9
Installing or removing the bit
Clean the bit shank and apply bit grease before installing the bit.
Insert the bit into the tool. Turn the bit and push it in until it engages.
If the bit cannot be pushed in, remove the bit. Pull the chuck cover down a cou-
ple of times. Then insert the bit again. Turn the bit and push it in until it
engages.
After installing, always make sure that the bit is securely held in place by trying
to pull it out.
To remove the bit, pull the chuck cover down all the way and pull the bit out.
1. Bit shank
2. Bit grease
2
1
003150
1. Bit
2. Chuck cover
1
2
006318
1. Bit
2. Chuck cover
1
2
006333

Makita HR4010C Specifications

General

Impact rate	2750 bpm
Rated speed (max)	480 RPM
Impact energy (max)	9.5 J
Weight (including battery)	6713 g
Carrying case	Yes
Power source	AC

Weight and Dimensions

Depth	470 mm
