Makita KP0810C User Manual

7
(A)
(B)
(B)
(A)
(B)
(A)
(A) Front base (Movable shoe)
(B) Rear base (Stationary shoe)
Correct setting
Nicks in surface
Gouging at start
Gouging at end
Although this side view cannot
show it, the edges of the blades
run perfectly parallel to the rear
base surface.
Cause: One or both blades fails to
have edge parallel to rear
base line.
Cause: One or both blade edges
fails to protrude enough in
relation to rear base line.
Cause: One or both blade edges
protrudes too far in relation
to rear base line.
EN0004-1
Change of chip discharge direction
1
2
007643
Chip discharge direction can be changed to the right or
left. To change the direction, pull out the stopper while
turning it slightly backward and fit in it in one of two
openings on the opposite side of chip discharge so that
the recessed part fits to protrusion.
1
2
007801
Dust bag (accessory)
1
2
007687
Attach the dust bag onto the chip discharge opening.
The chip discharge opening is tapered. When attaching
the dust bag, push it onto the chip discharge opening
firmly as far as it will go to prevent it from coming off
during operation.
When the dust bag is about half full, remove the dust
bag from the tool and pull the fastener out. Empty the
dust bag of its contents, tapping it lightly so as to
remove particles adhering to the insides which might
hamper further collection.
1. Dust bag
2. Chip discharge
opening
1. Recessed part
2. Protrusion
1. Stopper
2. Chip discharge
opening

Makita KP0810C Specifications

General

Input power	1050 W
Power source	AC
Idle speed	12000 RPM
Vibration level	1.5 m/s²
Sound power level	92 dB
Planning width (max)	82 mm
Soft grip	Yes
Product color	Black, Blue
Chip thickness (max)	4 mm

Weight and Dimensions

Depth	167 mm
Width	296 mm
Height	177 mm
Weight	3400 g
