4
en
Operations
Switching ON/OFF Clear Message Codes
2 sec
Device is
turned OFF.
1x
Undo last action.
If the info icon appears with a
number, observe the instruc-
tions in section "Message
Codes".
Example:
Adjusting measuring reference
Distance is measured from the
front of the device.
1
Distance is measured from the rear
of the device (standard setting).
2
Distance unit setting
0.000m
0.00m
0.00ft
0‘00‘‘ 1/16
0.00in
0 1/16in
Switch between the
following units:
2 sec

Makita LD050P Specifications

General

Accuracy	± 2 mm
Laser Class	Class 2
Laser Type	635 nm, <1 mW
Dimensions	116 x 45 x 29 mm
Measuring Range	0.05m - 50m
Power Source	2 x AAA batteries
Weight	0.1 kg
Measurement Units	m / in / ft
Auto Power Off	Yes
