Makita LD050P User Manual

Makita LD050P
5
en
Measuring Functions
Measuring single distance
1
Aim active laser at target.
2
8.532 m
3
i
Target surfaces: Measuring
errors can occur when meas-
uring to colourless liquids,
glass, styrofoam or semi-per-
meable surfaces or when
aiming at high gloss surfac-
es. Against dark surfaces the
measuring time increases.
Permament measuring
1
2 sec
8.532 m
Aim active laser at target.
2
The last value mea-
sured is displayed.
Stops permanent measur-
ing.
3
Add / Subtract
7.332 m
1
The next meas-
urement is added
to the previous
one.
2
1x
2x
The next meas-
urement is sub-
tracted from the
previous one.
5.515 m
12.847 m
3
i
The result is shown in the
main line and the measured
value above. This process
can be repeated as required.
The same process can be
used for adding or subtracting
areas or volumes.

Makita LD050P Specifications

General

Accuracy	± 2 mm
Laser Class	Class 2
Laser Type	635 nm, <1 mW
Dimensions	116 x 45 x 29 mm
Measuring Range	0.05m - 50m
Power Source	2 x AAA batteries
Weight	0.1 kg
Measurement Units	m / in / ft
Auto Power Off	Yes
