Technical Data
* favourable conditions are: white and diffuse
reflecting target (white painted wall), low background
illumination and moderate temperatures.
** unfavourable conditions are: targets with lower or
higher reflectivity or high background illumination or
temperatures at the upper or lower end of the speci-
fied temperature range.
*** Tolerances apply from 0.05 m to 10 m with a confi-
dence level of 95%.
With favourable conditions the tolerance may deterio-
rate by 0.10 mm/m for distances between 10 m to
30 m and by 0.15 mm/m for distances above 30 m.
With unfavourable conditions the tolerance may dete-
riorate by 0.15 mm/m for distances between 10 m to
30 m and by 0.20 mm/m for distances above 30 m.
Distance measurement (ISO 16331-1)
Accuracy with favourable
conditions *
± 2.0 mm / 0.08 in ***
Accuracy with unfavourable
conditions **
± 3.0 mm / 0.12 in ***
Range with favourable
conditions *
50 m / 164 ft
Range with unfavourable
conditions **
35 m / 115 ft
Smallest unit displayed 1 mm / 1/16 in
Ø laser point
at distances
6 / 30 mm
(10 / 50 m)
General
Laser class 2
Laser type 635 nm, < 1 mW
Protection class IP54 (dust- and splash
water protected)
Autom. laser switch off after 90 s
Autom. power switch-off after 180 s
Battery durability (2 x AAA) up to 5000 measure-
ments
Dimension (H x D x W) 116 x 45 x 29 mm
4.57 x 1.77 x 1.14 in
Weight (with batteries) 0.10 kg / 3.527 oz
Temperature range:
- Storage
- Operation
-25 to 70 °C
-13 to 158 °F
0 to 40 °C
32 to 104 °F
Functions
Distance measuring yes
Min/Max measuring yes
Permanent measuring yes
Addition/Subtraction yes
Area yes
Volume yes
Pythagoras 2-point, 3-point
Memory 5 results

Makita LD050P Specifications

General

Accuracy	± 2 mm
Laser Class	Class 2
Laser Type	635 nm, <1 mW
Dimensions	116 x 45 x 29 mm
Measuring Range	0.05m - 50m
Power Source	2 x AAA batteries
Weight	0.1 kg
Measurement Units	m / in / ft
Auto Power Off	Yes
