Makita LD050P User Manual

Makita LD050P
Measuring Functions
7
en
Pythagoras (2-point)
1
3x
2
Aim laser at up-
per point.
3
4
Aim laser rectan-
gular at lower
point.
8.294 m
5
i
The result is shown
in the main line and
the measured dis-
tance above.
Pressing the meas-
uring key for 2 sec
in the function acti-
vates automatically
Minimum or Maxi-
mum measure-
ment.
Pythagoras (3-point)
1
4x
2
Aim laser at up-
per point.
3
4
Aim laser at rec-
tangular point.
5
6
Aim laser at lower point.
8.294 m
7
i
The result is shown in the main
line and the measured distance
above.
Pressing the measuring key for 2
sec in the function activates auto-
matically Minimum or Maximum
measurement.

Makita LD050P Specifications

General

Accuracy	± 2 mm
Laser Class	Class 2
Laser Type	635 nm, <1 mW
Dimensions	116 x 45 x 29 mm
Measuring Range	0.05m - 50m
Power Source	2 x AAA batteries
Weight	0.1 kg
Measurement Units	m / in / ft
Auto Power Off	Yes
