7 ENGLISH
Pressure gauge
1
32
►1. Unit button 2. Minus button 3. Plus button
Iftheobjecttobeinatedisconnectedtothetool,the
airpressureoftheobjectisdisplayedonthepressure
gauge when you turn on the tool. If nothing is connected
to the tool, the pressure gauge displays "0".
Youcansettheairpressureonthepressuregauge.To
changetheunit,presstheunitbutton.Toincreasethe
pressurevalue,presstheplusbutton.Todecreasethe
pressure value, press the minus button. You can set the
pressure value between 20 kPa (3 PSI) and 830 kPa
(121 PSI).
Lighting up the front lamp
1
2
►1. Lamp 2. Main power switch
CAUTION: Do not look in the light or see the
source of light directly.
When you turn on the tool by pressing the main power
switch, the lamp lights up. When you turn off the tool by
pressing the main power switch, the lamp goes out.
NOTICE: When the tool is overheated, the lamp
ickers. Cool down the tool fully before operating
the tool again.
NOTE: Use a dry cloth to wipe the dirt off the lens of
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
Storing adapter
12
3
►1. Sport ball needle 2. Presta valve adapter
3.Adapterholder
Theadapterscanbestoredintheadapterholderofthe
tool. Insert the sport ball needle into the Presta valve
adapter before attaching them to the adapter holder.
Storing hose
1
2
►1. Hose holder 2. Hose
Thehosecanbeattachedtothehoseholderofthetool.
