Mako 6500-M - Hardware Specification

• 6500-M specs 9
Hardware Specification
LAN
Interface
4 x Ethernet RJ45 10/100/1000 Mbps
ports. Auto crossover.
WAN Interface 1 x Ethernet RJ45 10/100/1000 Mbps
port. Auto crossover.
1 x RJ11 ITU G.992 VDSL2 1/2/2+ port
Power Supply External 100 or 240 V AC Input (50 or
60Hz). 12 V DC output.
USB Port For support functions
(i.e. manual conguration).
Chassis
Dimension
Length: 8.58 inches (218mmn)
Width: 8.58 inches (218mm)
Height: 1.57 inches (40mm)
Operating
Temperature
41° F to 104° F
5° C to 40° C
Humidity 10% to 90% relative, non-condensing
Hardware VPN
Encryption
Supported
Power
Consumption
10W - Typical
Compliance Specification
Network Protocols PPP over Ethernet (RFC 2516 PPPoE)
Electromagnetic
Compliance
EN55022 - CSPIR 22 Class B (EMC)
EN55024 - CSPIR 24 (Immunity)
FCC Part 15 Class B
Wireless
Compliance
EN 300328
Safety Standards CB, IEC 60950, EN 60950 &
AS/NZS 60950
NZ Telecoms PTC 257 (3G)
Environmental Lead-free and RoHS compliant
Firewall Stateful Packet Inspection
Wireless Specification
Channels 2
Supported
Standards
802.11 b/g/n
Bandwidth Up to 300 Mbps per channel
Security WPA2 Personal
Frequencies 802.11b/g: 2.412 GHz - 2.472 GHz
802.11n HT20: 2.412 GHz - 2.472 GHz
802.11n HT40: 2.422 GHz - 2.462 GHz
Other Integrated access point scanning
Wireless Multimedia (WMM)
QoS
Output Power < 100 mW (e.i.r.p.)
DSL2 Modem Specification
DSL ADSL2+, VDSL supporting 1Gbit/s
transfer speeds
Cellular Specification
Protocols 3G, 4G LTE
