Malabar 795 - Wiring Diagram

RED
- 29 -
NOTE: ALL PARTS IN STARTER ENCLOSURE EXCEPT ELECTRIC MOTOR
C
2 HP
50 FT POWER CORD
PLUG
GREEN
X1
X2
H1
H4
H3
H2
L3
L2
L1
T1
T2
T3
HEATER
CONTACTOR
TRANSFORMER
ELECTRIC
MOTOR
MOTOR
THERMOSTAT
P1
P2
START
4
3
BY OTHERS
CIRCUIT
BREAKER
HIGH VOLTAGE
FUSES
FUSE
WIRING DIAGRAM
CONNECTED FOR 460V 3 PHASE
Property of American Airlines
