Malabar 795 - Remote Control Kit Parts Breakdown; Remote Control Kit Diagram

11
TO LUBRICATOR
AND AIR PUMP
FROM LOWER
AIR VALVE
BRANCH TEE
1/2 NPT
78990 REMOTE CONTROL KIT
FIGURE 14
NO. QTY PART NO. DESCRIPTION
14 2 76158
15 8 397-010
16 A/R 491-044
17 2 78995
18 1 78997
19 4 321-028
20 4 363-003
21 2 394-033
22 2 394-034
23 1 394-031
24 3 321-080
25 3 362-002
26 3 351-012
TEE, RUN, 1/2 NPT
REDUCER, 1/2 MPT x 1/4 FPT
ELBOW, 1/2 T x 1/2 MPT
TUBE, 1/2 O.D. x .049 WALL
AIR VALVE
STUD, 5/16-18 x 3/4 LG
ALLEN NUT, 5/16-18
SPLIT LOCKWASHER, 5/16
TEE, BRANCH, 1/2 T x 1/2 MPT
TEE, 3/8 TUBE
TUBE, 3/8 O.D. x .065 WALL
ELBOW, 3/8 T x 1/4 MPT
RELEASE VALVE
- 28 -
NO. QTY PART NO. DESCRIPTION
1 1 713-029
2 1 714-003
3 3 722-013
4 A/R 732-001
5 1 421-004
6 2 392-001
7 2 359-001
8 5 363-002
9 1 723-033
10 1 723-007
11 A/R 732-010
12 3 722-014
13 1 85416
3
1
CAUTION PLACARD
SELF TAPPING SCREW, #6
SAFETY LOCK WIRE, .025 DIA
STRAP
PANEL
HHCS, 3/8-16 x 1 1/2 LG
SPLIT LOCKWASHER, 3/8
SPLIT BUSHING, 1/2 TUBE
SPLIT BUSHING, 3/8 TUBE
CLAMPING UNIT
HHCS, 5/16-18 x 2" LG
FLAT WASHER, 5/16
HEX NUT, 5/16-18
TO CYLINDER
10
TO VALVE
BLOCK
12
TO LOWER
AIR VALVE
AIR INLET
TO AIR RELIEF VALVE
9
2
LOWER PANEL
14
15
LADDER
17
18
19
20
21
22
23
4
3
24
25
26
8
12
3
5
6
7
8
14
15
13
16
CYLINDER
