Malabar 95P10AR - Page 20

Model: 95P10AR
Two Stage Hydraulic Aviation Floating Auto-Retract Axle Jack
S/N 263 and Up
12/2018 | Rev. 01 Page | 20
Parts List – Figure 1A-1D
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
885598
BASE & CYLINDER ASSY
1
2
880430
FRAME AND RESERVOIR
1
3
492-012
SWIVEL CASTER
2
4
492-002
WHEEL
1
5
86399F
VALVE BLOCK & HAND PUMP
1
6
390-022
LEAD AND WIRE SEAL
1
7
86355
TOW HANDLE
1
8
86392
BUMPER
1
9
86352
LINK
1
10
86353
ROD
1
11
86354
SPRING PUSHER
1
12
371-007
ROLL PIN, 5/16 DIA x 1 1/2 LG
2
13
52526
SPRING
1
14
86350
YOKE
1
15
85414
TOW HANDLE BOLT
1
16
86351
YOKE PIN
1
17
86371
CUSHION TUBE
1
18
491-045
WIRE, .08 DIA x 12" LG
AR
19
86316
YOKE BEARING PAD
1
20
86329
HYDRAULIC HOSE
1
21
873840
HYDRAULIC HOSE
1
22
491-059
CABLE, TIE
1
23
86376
PUMP HANDLE
1
24
490-011
ACCUMULATOR
1
25
874616
ACCUMULATOR STRAP
4
26
874615
ACCUMULATOR MOUNT BRKT
1
27
86361
RESERVOIR COVER
1
28
86378
BRIDGE
1
29
86370
RESERVOIR COVER GASKET
1
30
86339
BREATHER CAP & DIPSTICK
1
31
85416
RELEASE VALVE
1
32
491-044
SAFETY LOCK WIRE, .025 DIA
AR
33
424-004
BYPASS VALVE
1
34
86367
CROSS CHECK VALVE
1
35
79367
SPRING
1
36
412-001
BALL, CHROME STEEL, 3/8 DIA
1
37
424-005
DRAINCOCK VALVE
1
38
423-037
RELIEF VALVE
1
39
423-038
DEFLECTOR CAP
1
40
372-002
COTTER PIN, 3/32 x 1" LG
5
41
721-009
CONNECTOR, 3/8 T x 1/4 MPT
5
42
721-102
CONNECTOR, 1/4 37º X 3/8 37º
2
