Malabar 95P10AR - Page 21

Model: 95P10AR
Two Stage Hydraulic Aviation Floating Auto-Retract Axle Jack
S/N 263 and Up
12/2018 | Rev. 01 Page | 21
Parts List – Figure 1A-1D
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
43
722-005
ELBOW, 3/8 37º X 1/4 MPT
1
44
722-010
ELBOW, 3/8 T x 3/8 MPT
1
45
722-093
ELBOW, 45º, 1/4 37º X 1/4 SAE
1
46
722-003
ELBOW, 3/8 37° x 3/8 SAE
1
47
713-012
TEE, RUN, 1/4 NPT
1
48
723-018
TEE, BRANCH, 3/8 T x 1/4 FPT
2
49
723-008
TEE, BRANCH, 3/8 T x 1/4 MPT
1
50
711-003
NIPPLE, 1/4 NPT
1
51
714-005
REDUCER, 1" MPT x 3/8 FPT
1
52
729-016
B-NUT, 3/8 37°
1
53
729-010
SLEEVE, 3/8 37°
1
54
732-010
TUBE, 3/8 OD x .065 WALL x 96"
AR
55
321-029
HHCS, 5/16-18 x 3/4 LG
2
56
321-011
HHCS, 3/8-16 x 1" LG
4
57
321-015
HHCS, 1/2-13 x 1 1/4 LG
8
58
321-039
HHCS, 1/2-13 x 3" LG
1
59
321-055
HHCS, 1/2-13 x 3 1/2 LG
1
60
880446
SCREW PIN
2
61
362-003
FLAT WASHER, 3/8 SAE
4
62
362-005
FLAT WASHER, 1/2 SAE
12
63
362-010
FLAT WASHER, 7/8 SAE THIN
1
64
363-002
SPLIT LOCKWASHER, 5/16
2
65
363-003
SPLIT LOCKWASHER, 3/8
4
66
363-004
SPLIT LOCKWASHER, 1/2
9
67
351-003
HEX NUT, 1/2-13
9
68
357-002
HEX NUT, SLOTTED, 1/2-13
1
69
363-021
HI-COLLAR LK WASH, 3/4
2
70
397-005
SELF TAP SCREW, #4 x 3/16 LG
14
71
55991-26
PLACARD, TONNAGE, 95 TON
1
72
872835
PLACARD, INSTRUCTION
1
73
86396
PLACARD, RELEASE VALVE
1
74
55998
STICKER, MALABAR
1
75
55994
STICKER, FLUID
1
76
75940
STICKER, TOWING
1
77
75942
STICKER, FLOATING
2
78
MS28778-4
O-RING (PART OF ITEM 45)
1
79
MS28778-6
O-RING (PART OF ITEM 46)
1
80
86391
HOLE PLATE (NO GAUGE)
1
81
MS51861-44C
SELF TAP SCR (NO GAUGE)
3
82
717-032
HEX CAP, 3/8 37° (NO GAUGE)
1
83
86336
COVER
1
84
365-004
O-RING SEAL WASHER, 5/16
4
