Malabar 95P10AR - Page 31

Model: 95P10AR
Two Stage Hydraulic Aviation Floating Auto-Retract Axle Jack
S/N 263 and Up
12/2018 | Rev. 01 Page | 31
Parts List – Figure 5
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
880460
Low Flow Air Pump Kit; consists of:
1
86387
AIR PUMP
1
2
86369
PUMP GASKET
1
3
880444
PUMP BRACKET
1
4
421-005
AIR VALVE, 3/8 NPT
1
5
425-001
AIR RELIEF VALVE, 1/4 NPT
1
6
472-001
MUFFLER, 1/2 NPT
1
7
481-002
OIL SCREEN, 1/2 NPT
1
8
722-013
ELBOW, 1/2 TUBE x 1/2 NPT
1
9
712-003
ELBOW, STREET, 1/2 NPT
1
10
713-005
TEE, BRANCH, 3/8 NPT
1
11
717-007
PLUG, HEX SOC, 3/8 NPT
1
12
711-013
NIPPLE, CLOSE, 1/2 NPT
1
13
711-099
NIPPLE, HEX LONG, 1/2 NPT
1
14
880467
NIPPLE, 1/2 MPT x 3/8 MPT
1
15
321-083
HHCS, 5/16-18 x 1" LG
1
16
714-009
REDUCER, 3/8 MPT x 1/4 FPT
1
17
86397
PLACARD, AIR
1
18
397-005
SELF TAP SCREW, #4 x 3/16
2
19
321-029
HHCS, 5/16-18 x 3/4 LG
2
20
323-069
SHCS, LOCKING, 5/16-18 x 3/4
4
21
363-002
SPLIT LOCKWASHER, 5/16
2
22
355-004
HEX LOCKNUT, 5/16-18
1
23
359-001
ALLEN NUT, 5/16-18
2
24
732-001
TUBE, 1/2 OD x .049 W x 21"
AR
25
714-006
REDUCER, 3/4 MPT x 1/2 FPT
1
26
722-012
ELBOW, 1/2 TUBE x 3/8 NPT
1
27
362-002
WASHER, FLAT 5/16 SAE
5
28
321-232
HHCS, 5/16-18 x 4 1/2 LG
1
