Procut 2600TC & 3000TC — User Manual
Cutter bar lubrication
Oil to be changed after first 50 operating hours, then every 600 operation hours
under normal operating conditions. Use SAE 90 (EP) gear oil or equivalent. Filler
plug is situated on top of cutter bar between 2
nd
& 3
rd
discs. To drain the oil from the
bar, leave the cutter bed supported the opposite side higher than the drain plug by
placing the bed on a block of wood, remove drain plug on underside of bar and
remove filler plug to aid draining oil. Ensure the oil has fully drained before putting
in fresh oil.
Product Oil Quantity
2600TC 3.6 Litres
3000TC 4.2 Litres
Cutter bed tilted for draining oil
Oil drain plug Oil fill plug
