Procut 2600TC & 3000TC — User Manual
Section 4 Transport
When travelling on public roads use accessory lights when necessary and
devices for adequate warning to other road users.
1. Raise the cutting unit by retracting the cutting unit cylinder.
2. Make sure the support leg is secured in the high position.
3. Swivel the drawbar into centre using drawbar cylinder.
4. Set drawbar locking plate in transport position.
5. Lift left and right side covers and secure with clips.
6. Close the hydraulic shut off valve.
7. If travelling on public roads ensure a ‘slow moving vehicle’ emblem is visible
to oncoming traffic.
8. If travelling on public roads always select a safe driving speed and allow faster
moving vehicles pass you safely.
Lift side covers and secure with clip
Fasten drawbar locking plate as shown
Retract cutting unit cylinders to raise
cutting unit
Shut off hydraulic transport valve
