TPS (Fig. 8)
• Identify the 5 cables TPS connector
located on the throttle body.
• On the yellow/green and red/blue
cables, apply the cable clamps
provided in the kit (Fig. 9).
• Make the following connections
using the cable clamp:
» Yellow Malossi control module
cable with red/blue TPS cable
» Brown Malossi control module
cable with yellow/green TPS
cable
WARNING:
once the faston is connected to the
electrical tap connector we suggest
to tape the wire bunch, to avoid
electrical tap vibrations damaging
the wires.
Coil
• Locate the SMALL faston (orange
wire) connected to the original coil
and disconnect it.
• Insert the faston which comes from
the Malossi ECU (orange wire) to the
original coil.
• Connect the original wire to the
ECU’s bypass to complete the
