Hardware features
42
For details on how to fill the cuvette with dispersant and then sample, refer to Filling the
cuvette on the facing page.
The sample cuvette can be removed to allow cleaning; the cuvette locks are rotated and
the complete cuvette can be removed. The cuvette windows are delicate and should be
treated with caution; refer to Hydro SV procedures on page97 for details on removing
the cuvette and cleaning the cuvette windows.
The cuvette has a maximum capacity of 7 ml in total:
Max. (7ml)
Min. (6ml)
l This corresponds to a minimum volume of 6 ml dispersant + 1 ml maximum of
sample. If more than 7 ml of sample/ dispersant is inserted the cuvette will over-
flow.
l
The maximum volume when filled to the bottom of the window chamfer is 7 ml.
l
The minimum volume when filled to the marks on the metal work as shown in
the illustration is 6 ml. This is the amount of dispersant that the cuvette must be
filled with to make sure the background measurements are suitable.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
