[Opening the light shield curtain]
[Closing the light shield curtain]
Before opening/closing the light
shield curtain, be sure to cock
the shutter, otherwise, it will not
open/close.
To open the light shield curtain, slide the
light shield curtain release lever along to fol-
low the arrow
down and right. This
will cause curtain to snap open.
The light shield lever indicator
-
(a white
line) is then aligned with
”
3
“.
Rotate the light shield closing lever in the
direction of the arrow, away from the open
position
”
2
”
and align the white indi-
cator on the lever with
”
@
”
to close.
l
When the light shield curtain is open, the lens
cannot
be removed. Close the curtain to
remove
the lens.
l
When the light shield curtain is closed, the shut-
ter cannot
be
released.
When taking a picture, open the light shield cur-
tain.
(If the light shield curtain is closed, a
red
LED will
indicate that it is closed.)
Never touch the light shield curtain or the
bellows. If touched, light leakage or a mal-
function may result.
13
