Technical data
46
Model D 0826 LE
Design in-line vertical
Cycle 4-stroke Diesel with turbocharging / inter-
cooling
Combustion system Direct injection
Turbocharging Turbocharger with intercooling
Number of cylinders 6
Bore 108 mm
Stroke 120 mm
Swept volume 6 596 cm
3
Compression ratio 17 : 1
Rating see engine nameplate
Firing order 1–5–3–6–2–4
Valve clearance (cold engine)
Intake 0.50 mm
Exhaust 0.50 mm
Valve timing
Intake opens 20° before TDC
Intake closes 12° after BDC
Exhaust opens 63° before BDC
Exhaust closes 29° after TDC
Fuel system
Injection In-line pump, with flange fastening
Governor All speed type
Injectors four-hole nozzles
Opening pressure of injector
New nozzle holder: 265 + 8 bar
Used nozzle holder: 250 + 8 bar
Fuel Filter Parallel box filter
Start of delivery  1° crank angle before TDC
(S )
Injection pump
Exhaust manifold
(Speed constant = without timing adjustment)
dry
liquid-
cooled
1500 1/min, constant 51.11102-7937 16° –
51.11103-7111 13° –
1800 1/min, constant 51.11102-7938 16° –
51.11103-7112 14° –
2600 1/min, variable – 15°
