Special tools
127
Fig. no. Designation Item number
10 Puller for water pump pulley 80.99601–0037
11 Pressing mandrel for cassette seal in conjunction with handle 14.1 80.99617–0091
12 Driving mandrel for seal in timing case
consisting of:
12.1 Guide sleeve 80.99604–0068
12.2 Pressing plate in conjunction with handle 14.1 80.99604–0069
13 Puller for front crankshaft bearing race 80.99601–0076
14 Pressing tool for bearing race on flywheel in conjunction with handle 14.1 80.99617–0017
14.1 Handle 80.99617–0129
15 Special tools for front crankshaft seal 80.99606–6011
Components:
15.1 Spindle 80.99606–0229
15.2 Extractor device 80.99606–0298
15.3 Adapter 80.99606–0264
15.4 Extractor hook 80.99606–6013
15.5 Pressing sleeve 80.99606–0300
15.6 Adapter 80.99606–0302
15.7 Fitting sleeve 80.99606–0301
16 Guide mandrels for flywheel 80.99617–0020
17 Steel ruler 80.99607–0044
18 Engine turning device 80.99626–0004
18.1 Standard ratchet for 18 80.99627–0001
