Man D 2876 LE 403 - Removing and Installing Fuel Injectors

1
2
3
4
Removing and installing fuel injectors
30
Removing fuel injectors
Fig. 1
Remove leakage fuel return lines.
Fig. 2
Remove injection lines.
Fig. 3
Remove pressure screw from fuel injector using a
pin spanner.
Fig. 4
Bolt inertia puller on to fuel injector and knock out
the injector.
3402
3403
3378
3404
