Special tools
132
31
1
2
3
4
5
6
32
33
Fig. no. Designation Item number
31 Measuring combination, consisting of:
(1) Dial gauge 08.71000–1205
(2) Tracer pin for dial gauge 80.99605–0197
(3) Dial gauge holder 80.99605–0179
(4) Contact pin 80.99605–0180
(5) Dial gauge holder 80.99605–6006
(6) Dial gauge holder 80.99605–0172
32 Press–on measuring plate 80.99605–0195
33 Fitting sleeves 51.91701–0247
