10
11
12
Removing and installing oil pump
56
Installing oil pump
Fig. 10
Before installing, check whether the oil pump(s)
run(s) smoothly and then fit it/them free of tension
(13 mm).
Figs. 11 and 12
Fit the oil intake lines À with seals and the oil re-
turn lines Á without seals so that they are free of
tension (13 mm). Screw on pressure–relief valve
without seal (13 mm).
Before mounting the oil pan, turn over the engine
to check whether the crankgear and the oil pumps
run unimpeded and smoothly.
Stick new oil-pan gasket on to oil pan using grease
and then bolt oil pan into place.
3588
3460
1
2
3461
