Man D 2876 LE 403 - Page 79

5
6
Removing and installing intercooler
78
Disassembling and cleaning
intercooler
Fig. 5
Remove charge-air elbow (13 mm).
Fig. 6
Clean the fins on the intercooler of oil and resi-
dues, using a steam jet cleaner.
Do not damage the fins.
3487
3489
