Maintenance and care
113
Change air filter
Danger:
Only replace the air filter with the engine
switched off
Remove air filter
Loosen the hose clamp (2) and remove the air fil
ter (1) from the intake neck (3).
Removal of the second air filter takes place by
analogy.
Mount air filter
Slide the new air filter (1) onto the intake neck (3).
Position the hose clamp (2) and tighten to 7 Nm.
Mounting the second air filter is analogous to the
first.
1
3
2
