Open the battery compartment by removing the thumbscrews and then sliding the
battery cover up and off.
Locate the 3 battery contact pins in the bottom-right corner of battery
compartment.
Push the 3-pin battery connector onto the contact pins.
Place the battery into the battery compartment and replace the battery cover. Slide
the cover back so that the screw holes are aligned.
Replace the thumbscrews.
Caution
We recommend replacing the battery provided by the
AED7000 service provider or one that matches the
standard battery parameters of the AED7000.
WARNING!
The replaced battery doesn’t match the standard
battery parameters may cause serious damage to the
AED7000.
