8 TECHNICAL SPECIFICATIONS
Gas conditioning series CSS ® Version CSS-VC1 Version CSS-VC2
Article number 230 V 50 Hz
01G6050
01G6055
Article number 115 V / 50-60 Hz
01G6050a
01G6055a
Gas outlet dew point
Setting range: + 2 °C ..... + 7 °C [35.6 … 44.6 °F],
factory setting: + 5 °C [41 °F]
Dew point stability
Under constant conditions < ± 0.1 ° C [±0.18 °F]
Gas inlet temperature
Max. 180° C** [356 °F]**
Gas inlet water-vapour saturation
Max. + 80 ° C** [176 °F]**
Gas flow
**Max. 250 Nl/h
**Max. 2 x 150 l/h
Ambient temperature
10 to + 40 °C** [50 to 104 °F]**
Storage temperature
-25 to + 65 °C [-13 to 149 °F]
Pressure
0.7 bar to 1.4 bar abs.
Total cooling capacity **
Max. 144 kJ/h
Number of gas inlets
1
2
Number of gas outlets
1
2
Condensate connection
1
2
Medium connections
Hose connection 4/6 mm
Material of parts in contact with
medium
Heat exchangers: Glass, PVDF or stainless steel 1.4571
Hoses/screwed connectors: PTFE/PVDF
Universal filter e.g. FP-2T-D: PVDF, FPM, glass, PTFE
Front-installed filter FPF-0.1GF: PVDF, glass, FPM
Front-installed filter FPF-2-0.3GF: PVC, FPM, PPH
Peristaltic pump SR25.2: PVDF, Novoprene ®
Liquid particle e.g. CLF-5/W: PVDF, glass, FPM, PTFE
Sample gas pumps N3/5/9: PVDF, PTFE, FPM
Flow meter FM40: PVDF, glass, FPM, Hastelloy C4
Ball valve 3L/PV and 5L/PV: PVDF, FPM
Operational
Approx. 10 minutes.
Mains connection
230 V 50-60 Hz ±10 % or 115 V 50-60 Hz ±10 % ***
Power input
Max. 220 VA + max. 300 VA for sample gas pumps
Device fuse
6.3 A time-lag, 5 x 20 mm
Electrical connection
- Cold-device connector with 2 m cable
- Single alarm connections (11 & 12-pole) or status alarm(s)
(6-pole) : maximum capacity of the relays 24 V 500 mA
- mA-outlet : maximum load 500 Ohm, accuracy ±2 % of
measuring range end value for display indication
- M&C Bus
- Heated sample line : maximum length 10 m [≈ 82.81 ft]
Device protection class IP20 to EN 60529
Housing design
Steel housing for 19"- or wall mounting, painted RAL 7035
Device dimensions (H x W x D)
267.5 x 483 x 301.5 mm [≈ 10.53” x 19.02” x 11.87”]
(Portable version: 355 x 515 x 395 mm [≈ 13.98” x 20.28” x 15.55”])
Electrical device standard
EN 61010
FPM = Viton ®
PVDF = Polyvinylidene fluoride
PVC = Polyvinyl chloride
FPM = Fluorinated rubber
PPH = Hard polypropylene
PTFE = Polytetrafluoroethylene
**Technical specifications with maximum values must be rated in consideration of total cooling capacity at 25 °C [77 °F] and an outlet dew point of 5 °C [41 °F].
*** 115 V / 50 Hz sample gas pump available as a special item
