19 SPARE PARTS LISTS
The wear and spare part requirements depend on specific operating conditions. The recommended
quantities are based on experience and are not binding. They refer to the version of CSS-VC.. with a
gas line.
Gas conditioning version CSS-VC..
(C) Consumable parts,
(R) Recommended spare parts
(S) Spare parts
Recommended quantity
in operation [years]
Article No.
Description
C/R/S
1
2
3
FPF-0, 1GF
90F0009
Filter element type F-0,1GF material: glass fiber
filtration fineness: 0.1 μm
C
6
12
18
90F0045
O-ring for FPF, material: Viton
®
.
R
1
1
1
90F0118
Replacement filter glass F-45
R
1
1
1
FPF+
90F0044
O-ring (35) for FPF. Material: Viton.
R
1
1
1
90F0210
Filter glass FPF+
R
1
1
1
90F0002
Filter element type F-2T. Length: 75 mm, material:
PTFE filtration fineness: 2 μm
R
6
12
18
90F0004
Filter element type F-20T. Length: 75 mm,
material: PTFE filtration fineness: 20 µm
R
6
12
18
90F0003
Filter element type F-50T. Length: 75 mm,
material: PTFE filtration fineness: 50 µm
R
6
12
18
90F0005
Filter element type F-3G. Length: 75 mm, material:
Glass, filter fineness: 3 µm
R
6
12
18
90F0011
Filter element type F-2GF. Length: 75 mm,
material: Fiberglass filter fineness: 2μm. Pack of
25 pcs. (For assembly 2 x adapter rings type No.
93S0050 are required)
R
1
2
3
90F0016
Filter element type F-0, 1GF. Length: 64 mm,
material: Fiberglass filter fineness: 0.1 µm. (For
assembly 2 x adapter rings Art. No.. 93S0050 are
required)
R
6
12
18
90F0550
Filter element type F-0,05SIC. Length: 75 mm,
material: Ceramic, filtration fineness: 0.05 µm.
R
6
12
18
90F0006
Filter element type F-2K. Length: 75 mm, material:
Ceramic, filtration fineness: 2 μm
R
6
12
18
90F0007
Filter element type F-20K. Length: 75 mm,
material: Ceramic, filtration fineness: 20 µm
R
6
12
18
90F0008
Filter element type F-3SS. Length: 75 mm,
material: SS 1.4404, filtration fineness: 3 µm
R
6
12
18
90F0010
Filter element type F-20SS. Length: 75 mm,
material: SS 1.4404, filtration fineness: 20 µm
R
6
12
18
93S2083
Spec. Glass wool resistant to high temperatures,
for filter wool receiving element FW. Content:
1000 g
R
1
2
3
93S0050
Adapter ring for filter element F-0,1GF and F-
2GF. Material: PTFE (1 pc.)
R
-
-
2
Universal filter (replacement filter elements see FPF+)
90F0040
O-ring (26) for the filter head. Material: Viton.
R
2
4
6
90F0045
O-ring (26) for the filter head. Material: FEP.
R
2
4
6
90F0012
Replacement filter glass type F-120G
S
-
-
1
90F0015
Replacement filter glass type F-120G-D with
condensate connection thread GL25
S
-
-
1
