m&h Inprocess 40.01-TX - Probe Operational Angles and Signal Transmission; Probe ON;OFF Angle Settings; Transmitting and Receiving Capabilities

Infrared Probe 40.01
-
TX/RX
2
O
N
OF
F
0
V
>10VD
C
<1s
<1
,
5s
M-Code
Probe ON / OFF Angle – during ON / OFF
Transmitting / Receiving
= Receiving
= Transmitting
= Receiving
= Transmitting
Infrared Probe
40.01-TX/RX
Adjustable Range
≤1.6m (5.2´)
≤3.3m (10.8’)
≤4.0m (13.1´)
Infrared Receiver
91.40-RX/TX/°C
ON/Off Range
≤4.0m (13.1’)
alternative
Infrared Receiver
91.30-RX/TX
ON/OFF Adjustable Range
≤1.5m (4.9’)
≤2.2m (7.4´)
≤3.0m (9.8´)
ON/OFF Pro
c
edure
