2-19
CHARACTERISTICS OF 180 ATJ 2 E3 & 180 ATJ 2 E3 RC
INTERNAL COMBUSTION ENGINE UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel
18” TOL ±
Type KUBOTA V1505-E3B -
Fuel Diesel -
No. of cylinders 4-
Cubic capacity Cm3 1498 -
Idling speed, unladen rpm 1000 50
Max engine revs, unladen rpm 3000 20
ISO power/ rpm (at 3000 rpm) CV - KW 26.2 -
Max torque (at 2300 rpm) Nm 92 -
Fuel consumption per hour L/h 1.92
No. of cycles / fuel consumption test
No. of cycles
/ h
6
Unladen weight Kg 110 5
Air filtration μm - -
Type of cooling AIR -
Fan SUCTION -
LwA acoustic pressure level dBA 104 -
TRANSMISSION UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel
18” TOL ±
Type HYDROSTATIC
Pump A10VG45
Supplier BOSCH - REXROTH
Cylinder capacity (hydraulic transmission) Cm3 46
Max service pressure bar Dr 305 5 %
Hydrostatic motor A10FM63
Supplier BOSCH-REXROTH
Cylinder capacity Cm3 63
Axle Type 26 - 20
Supplier CARRARO
Reduction ratio 52.36
Traction power daNm 3130 2790 -
Front axle differential
SLIPPAGE LIMIT 45%
Rear axle differential Hydraulic lock 100%
No. of steered wheels, front / rear 2 / 2
No. of driven wheels, front / rear 2 / 2
BRAKING CIRCUIT (parking brake) UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel
18” TOL ±
Type of brake Negative
Type of control Hydraulic
Braked wheels 2 rear wheels
Brake release (freewheeling) Manual, on axle
Braking torque daNm 1600 at the wheel 5 %
LEVEL OF VIBRATIONS UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel
18” TOL ±
Quadratic average values for the body m/s² < 0,5 -
647414 EN (27/05/2015)
