2-20
CHARACTERISTICS OF 180 ATJ 2 E3 & 180 ATJ 2 E3 RC
CIRCUIT HYDRAULIC UNIT 180 ATJ 2 E3 180 ATJ 2 E3 Wheel 18” TOL ±
Auxiliary hydraulic pump
Type fixed Cubic capacity BOSCH
Cubic capacity Cm3 16 -
Max flow rate, unladen l/min 48 -
Max permanent service pressure bar 230 5 %
Filtration
Return μm - -
Suction μm 100 (ß10) -
Pressure μm 10 -
ELECTRICAL CIRCUIT UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel 18” TOL ±
Battery
C5 capacity Ah 105 -
Nominal voltage V 12 -
Type Starting
Alternator
Type --
Intensity A 40 -
Voltage V 12
Starter
Type --
Power Kw - -
Voltage V 12 -
EMERGENCY PUMP UNIT 180 ATJ 2 E3 180 ATJ 2 E3
Wheel 18” TOL ±
Type Electric -
Cubic capacity Cm3 2.0 -
Power Kw 1.3 -
Voltage V 12 -
Intensity at 150 bars A - -
Integral thermal cut-off YES
S2 mn 6.2 min at 100 b -
S3 % 10.3 % at 100 b -
647414 EN (27/05/2015)
