Menu Pump Upper Box Pers Parameters Hydraulic Functions Average value Time target
Basket codes
120AETJL 150AETL/C 170AETJL 120AETJL 150AETL/C 170AETJL
2.3.1 Boom 1 Up Speed (%) Lifting speed arm 1 & 2 100 17 45
2.3.2
Boom 1 Down Speed (%)
Lowering speed arm 1 & 2
42
65
26
45
2.3.3 Boom 1 Cutback Speed (%) Speed limit arm 1 & 2 100 100
2.3.4 Boom 2 Up Speed (%) Lifting speed arm 3 telescope extended 73 70 67 24 38 48
2.3.5
Boom 2 Down Speed (%)
Lowering speed arm 3 telescope extended
42
38
30
24
34
36
2.3.6 Boom 2 Cutback Speed (%) Speed limit arm 3 100 100
2.3.7 Jib Up Speed (%) Speed jib lifting (%) 36 16
2.3.8
Jib Down Speed (%)
Jib lowering speed (%)
20
18
2.3.8A Jib Rotate Left Speed (%) Jib left rotation speed (%) 1 1
2.3.8B Jib Rotate Right Speed (%) Jib right rotation speed (%) 1 1
2.3.9
Tele In Speed (%)
Speed telescope retraction (%)
100
12
15
17
2.3.10 Tele Out Speed (%) Speed telescope extension (%) 100 24 19 23
2.3.11 Slew Left Speed (%) Speed left rotation turret (%) 29 23 26 80 88 120
2.3.12
Slew Right Speed (%)
Speed right rotation turret (%)
29
23
26
80
88
120
2.3.13 Cage Rotate Left Speed (%) Speed left rotation basket (%) 24 7
2.3.14 Cage Rotate Right Speed (%) Speed right rotation basket (%) 24 7
2.3.15
Cage Level Forward Speed
(%)
Speed tilting bucket (%) 62 25
2.3.16
Cage Level Reverse Speed
(%)
Speed tilting spill (%) 28 25
2.3.17 Y-Axis Forward Voltage (V) Front travel voltage (V) 4.06 4.06
2.3.18 Y-Axis Reverse Voltage (V) Rear travel voltage (V) 0.52 0.52
2.3.19
X-Axis Left Voltage (V)
Zero position (X-axis) voltage (V)
0.52
0.52
2.3.20 X-Axis Right Voltage (V) Max voltage (X-axis) (V) 4.06 4.06
Speed travel movement over 10 m (s) 100 8
Speed travel working over 10 m (s)
13
60
Menu Pump Lower Box Pers Parameters Hydraulic Functions Base Codes Mini display Maxi display Pitch Value
2.5.1 Boom 1 Up Speed (%) Lifting speed arm 1 & 2 0 100 1 100
2.5.2 Boom 1 Down Speed (%) Lowering speed arm 1 & 2 0 100 1 90
2.5.3
Boom 1 Cutback Speed (%)
Speed limit arm 1 & 2
0
100
1
100
2.5.4 Boom 2 Up Speed (%) Lifting speed arm 3 telescope extended 0 100 1 100
2.5.5 Boom 2 Down Speed (%) Lowering speed arm 3 telescope extended 0 100 1 70
2.5.6
Boom 2 Cutback Speed (%)
Speed limit arm 3
0
100
1
25
2.5.7 Jib Up Speed (%) Speed jib lifting (%) 0 100 1 90
2.5.8 Jib Down Speed (%) Jib lowering speed (%) 0 100 1 75
2.5.9
Tele In Speed (%)
Speed telescope retraction (%)
0
100
1
100
2.5.10 Tele Out Speed (%) Speed telescope extension (%) 0 100 1 100
2.5.11 Slew Left Speed (%) Speed left rotation turret (%) 0 100 1 60
2.5.12
Slew Right Speed (%)
Speed right rotation turret (%)
0
100
1
60
2.5.13 Cage Level Forward Speed (%) Speed left rotation basket (%) 0 100 1 50
2.5.14 Cage Level Reverse Speed (%) Speed right rotation basket (%) 0 100 1 60
2.5.15
Cage Rotate Left Speed (%)
Speed tilting bucket (%)
0
100
1
50
2.5.16 Cage Rotate Right Speed (%) Speed tilting spill (%) 0 100 1 50
2.5.17 Overload Cutback Speed (%) Overload speed limit (%) 0 100 1 50
