TEST MENUS
Menu Traction Status Status (Variable Speed Controller) Mini display Maxi display Pitch Log. Info
1.2.1
Battery Voltage
Battery voltage
0 V
127 V
0.1
+
1.2.2 Armature Motor Voltage Armature Voltage 0 V 127 V 0.5
1.2.3 Field Motor Voltage Field voltage 0 V 127 V 0.5
1.2.4
Armature Motor Current
Armature current
0
625 A
0.20833333
+
1.2.5 Field Motor Current Field current 0 64 A 0.25 +
1.2.6 Armature MOSFET Voltage MOSFET voltage 0 V 127 V 0.5
1.2.7
Controller Temp.
Temperature variable speed controller
-30 °C (-22 °F)
+225 °C (+437 °F)
1
+ –
1.2.8 Capacitor Voltage Capacitor Voltage 0 V 127 V 0.5
1.2.9 Speed estimation Speed measurement 0 1 0.005
1.2.10
Speed estimation
Speed measurement
0 Km/H (0 mph)
60 Km/H (37.28 mph)
1.0
1.2.11 Speed estimation Speed measurement 0 MPH 60 MPH 1.0
1.2.12 Key Switch Hours Count Hour meter operation 0 Hrs 65279.9 Hrs 0.1
1.2.13
Traction Pulsing Hours Count
(Drive)
Hour meter travel 0 Hrs 65279.9 Hrs 0.1
1.2.14 CAN fail node CAN fault note: 2 None
Output,
EOutput
n/a
1.2.15 CAN error count CAN meter error - - -
1.2.16 CAN error code CAN coding error - - -
Service Log Reset
RAZ memory faults
Press + then - to reset Service Log
Menu Traction Test Variable speed controller Mini display Maxi display Pitch Log. Info
1.3.1 Accelerator % Accelerator % 0% 100% 1% range
1.3.2 Accelerator Voltage Accelerator Voltage 0.0 V 5.0 V 0.02 V range
1.3.3
Deadman
Fail-safe
Open
Closed
–
Switch
1.3.6 Steer left LH steering Open Closed – Switch
1.3.7 Steer Right RH steering Open Closed – Switch
1.3.8
Horn
Horn
Open
Closed
–
Switch
1.3.9 Traction select Traction select Open Closed – Switch
1.3.10 Tilt Tilt input Open Closed – Switch
1.3.11
Boom Rest
Arm down sensor
Open
Closed
–
Switch
1.3.12 Tele sw. Extended telescope sensor Open Closed – Switch
1.3.13 Brake Release Brake sensor released Open Closed – Switch
1.3.14
BDI Input
BDI Input
Open
Closed
–
Switch
1.3.15 Frame Fault Earth detection Open Closed – Switch
1.3.16 Cage Ovl2 Overload detection no. 2 Open Closed – Switch
1.3.18
Joystick NTRL sw
Contact joystick not neutral
Open
Closed
–
Switch
1.3.19 LS Traction sw Select low speed traction Open Closed – Switch
1.3.20 Ver xxxxxxx Software version xxxxxx xxxxxx
1.3.21
Controller Serial Number
Variable speed controller serial number
0
99999999
–
1.3.22 Controller type Power type xxnnn –
Menu Pump Status Variable speed controller (hydraulic functions) Mini display Maxi display Pitch Log. Info
2.2.1 Battery Voltage Battery voltage 0 V 127 V 0.1 V +
2.2.2
Motor Voltage
Motor Voltage
0 V
127 V
0.5 V
2.2.3 Motor Current Motor Current 0 625 A 0.20833333 +
2.2.4 MOSFET Voltage MOSFET voltage 0 V 127 V 0.5 V
2.2.5 Controller Temp. Microprocessor temperature -30 °C (-22 °F)
+225 °C (+437 °F)
1 °C (33.8 °F) + –
Service Log Reset RAZ memory faults Press + then - to reset Service Log
