22
2
MHT 10120 L M
Series
2
2
5
5
-
- TOWBAR
On the rear of the truck, the towbar allows towing of a trailer. For each truck,
the towing capacity is limited by the total authorised weight for travel on the
public highway, the traction force and the maximum vertical stress on the tow-
ing pin. These data are shown on the manufacturer’s data plate applied to
each truck.
N.B. : Other optional solutions are available for towing trailers; for
further information, contact your agent or dealer.
- Only trucks registered as agricultural tractors are
allowed to tow trailers on the public highway.
- Check the trailer’s braking and light systems and
connect them to the truck.
- Reduce the speed of the truck.
- Follow your country’s highway code.
Make sure that the split-pin is properly positioned on the towbar
2
2
6
6
-
- FRONT LIGHTS
A - Front left direction indicator light.
B - Front left side-light.
C - Front left dipped headlight and full beam
headlight.
D - Front right side-light.
E - Front right dipped headlight and full beam head-
light.
F - Front right direction indicator light.
2
2
7
7
-
- REAR LIGHTS
A - Rear left direction indicator light.
B - Rear left brake light.
C - Rear left side-light.
D - Rear left reversing light.
E - Rear right reversing light
F - Rear right side-light.
G - Rear right brake light.
H - Rear right direction indicator light
.
B
C
D
E
F
A
A B C D
HGFE
