4 - 9
STANDARDISED TILTING FORK CARRIAGE
PFB 35 N MT-1260 S2 PFB 35 N MT-1470 S2 PFB 35 N MT-1580 S2
PART NUMBER
653744 653745 653746
Rated capacity
3500 kg 3500 kg 3500 kg
Width
1260 mm 1470 mm 1580 mm
Weight
95 kg 120 kg 125 kg
STANDARDISED FORK
PART NUMBER 415618
Section 125x45x1200 mm
Weight 72 kg
STANDARDIZED TILTING FORK CARRIAGE + STANDARDIZED SIDE-SHIFT CARRIAGE
PFB 35 N 1260 DL PFB 35 N 1580 DL
REFERENCE 52000101 52000102
Rated capacity 3150 kg 3150 kg
Side-shift 2x100 mm 2x100 mm
Width 1260 mm 1580 mm
Weight 175 kg 300 kg
STANDARDIZED TILTING FORK CARRIAGE + LOAD BACK REST
PFB 35N 1260 LB PFB 35N 1470 LB
REFERENCE
52000200 52000201
Rated capacity
3500 kg 3500 kg
Width
1260 mm 1470 mm
Weight
130 kg 158 kg
STANDARDIZED TILTING FORK CARRIAGE + STANDARDIZED SIDE-SHIFT CARRIAGE + LOAD BACK REST
PFB 35 N 1260 DL/LB
REFERENCE 52000205
Rated capacity 3150 kg
Side-shift 2x100 mm
Width 1260 mm
Weight 210 kg
647449 (30/11/2015) MT 732/932 ST3B
