3B - SCREEN DISPLAY
- Turn on the lift truck ignition using the ignition key.
- The initialization screen appears, please wait.
- The screen
appears to show:
• The direction of travel (F for forward/R for reverse/N for neutral).
• The hour meter.
• The clock.
- Short press button A to move successively from one screen to another, hold
down the button to enter the menus.
Main screen.
To set the time, short press to increment the value or hold down
tomove to the next number.
Daily hour meter screen.
Reset to zero.
Engine fault screen.
Fault code display.
ECU fault screen.
Fault code display.
Instantaneous consumption screen.
Main screen.
HELP SCREENS
Self-cleaning fan,these screens are displayed for 3 seconds (see: 2 - DESCRIPTION: 6 - SWITCHES).
WARNING SCREENS
This screen is displayed for 3 seconds every 10 minutes in the event that there is water in the diesel. Drain the
fuel pre-filter (see: 3 - MAINTENANCE: A - DAILY OR EVERY 10 HOURS OF SERVICE).
A
647449 (30/11/2015)
MT 732/932 ST3B
