2 - 39
5 - EMERGENCY STOP BUTTON
In the event of danger, it enables the engine to be shut down, thereby cutting-off all
hydraulic movements.
IMPORTANT
Warning, hydraulic movements suddenly stop when using this button.
If possible, stop the lift truck before using the emergency stop.
- Turn the knob to deactivate it before restarting the lift truck.
6 - SWITCHES
NOTE: The location of the switches may vary depending on the options.
A - BOOM ELECTRICAL PREDISPOSITION OPTION
OR
HEAD TELESCOPE ELECTROVALVE OPTION
See: 2 - DESCRIPTION: DESCRIPTION AND USE OF THE OPTIONS.
B - BLUE FRONT AND REAR WORKING LIGHTS OPTION
C - WHEEL ALIGNMENT LAMPS
See: 2 - DESCRIPTION: 20 - STEERING SELECTION.
D - HAZARD WARNING LIGHTS
E - REAR FOG LIGHTS
F - SELF-CLEANING FAN OPTION
Cleans the radiator core and the grille of the engine cover by reversing the air flow.
IMPORTANT
The self-cleaning fan is operational as from an engine water temperature of 40°C.
Beware of the risk of splashes in the eyes.
- Position 1: The help screen comes on for 3 seconds, the indicator lamp is lit, the fan operates in self-
cleaning mode for a few seconds once every 3 minutes.
- Position 2: The help screen comes on for 3 seconds, indicator lamp is off, the fan is in normal operating
mode.
G - STEERING SELECTION
See: 2 - DESCRIPTION: 18 - STEERING SELECTION.
H - TRANSMISSION CUT-OFF
NOTE: In all cases transmission cut-off can be activated using the gear lever.
- Position 1: Indicator lamp is on, transmission is cut-off with the service brake pedal and the forward/neutral/reverse
gear lever.
- Position 2: Indicator lamp is off, transmission is cut-off with the forward/neutral/reverse gear selector.
USE OF TRANSMISSION CUT-OFF
- Transmission cut-off to brake pedal (position 1).
• When loading.
- Transmission cut-off with forward/neutral/reverse gear selector (position 2).
• When driving.
• For inching and continuous stop/start (delicate handling).
• Start-up on a slope.
5
A B C D
E F G H
11
22
647449 (30/11/2015)
MT 732/932 ST3B
