43 - BOOM SAFETY WEDGE

IMPORTANT

Only use the wedge supplied with the lift truck.
The lift truck is equipped with a boom safety wedge that must be installed on the rod of
the lifting cylinder when working beneath the boom (see: 1 - OPERATING AND SAFETY
INSTRUCTIONS).
42 - ROTATING BEACON LIGHT
The magnetic rotating beacon light must be clearly visible on the roof of the cab and
plugged-in to socket 1.
41 - REAR LIGHTS
• A - Left rear indicator.
• B - Left rear stoplight.
• C - Left rear headlight.
• D - Left rear reverse light.
• E - Left rear fog light.
• F - Right rear fog light.
• G - Right rear reverse light.
• H - Right rear headlight.
• I - Right rear stoplight.
• J - Right rear indicator.
40 - FRONT HEADLIGHTS
• A - Left front indicator.
• B - Left front dipped beam headlight.
• C - Left front main beam headlight.
• D - Left front sidelight.
• E - Right front indicator.
• F - Right front dipped beam headlight.
• G - Right front main beam headlight.
• H - Right front sidelight.
