Manitowoc 777 User Manual

Reference Only
Manitowoc Published 10-01-12, Control # 044-05 4-69
777 OPERATOR’S MANUAL SET-UP AND INSTALLATION
4
Pad
Eye
Rope
Clips
P1519
Wire
Rope
Sucker
Line
Wire
Rope
FIGURE 4-45
A1189
Pad
Eye
Wire Rope
from Drum
Pad
Eye
Sucker
Line
Load Block
Sheaves
Boom Point
Sheaves
Pull Sucker Line
with Winch or
Fork-Lift Truck
Sucker
Line
B
D
E
G
C
A
F
No. 1.5 Pad Eye Item Inch mm
Approximate Capacity 1,220 lb (553 kg) A 5/8 16,00
B 1/4 6,35
C 1 25,40
D 7/16 11,18
E 1-1/8 28,70
F 1/16 4,06
G 1-5/16 33,27
No. 1 Pad Eye Item Inch mm
Approximate Capacity 1,220 lb (553 kg) A 3/8 9,65
B 1/4 6,35
C 7/8 22,40
D 13/32 10,40
E 7/8 22,40
F 1/8 3,30
G 1-1/32 25,40
No. 2 Pad Eye Item Inch mm
Approximate Capacity 2,600 lb (1 179 kg) A 3/4 19,05
B 3/8 9,65
C 1-1/16 26,92
D 1/2 12,70
E 1-1/2 38,10
F 3/16 4,83
G 1-5/8 41,26
