OPERATING PROCEDURES GRT655/655L OPERATOR MANUAL
4-86 Published 3-23-2020, Control # 654-04
Five different sensitivity curves are available to select from
(curves 1 through 5). Sensitivity curve 1 is the default curve
and causes the function speed to increase or decrease
equally with an equal amount of movement of the controller
(Figure 4-55).
Selecting a sensitivity curve of 2 through 5 causes the
function speed to be reduced, from the default sensitivity
curve 1, relative to the same controller position over the full
travel of the controller (Figure 4-56). Sensitivity curve 1
(default) is the most sensitive and sensitivity curve 5 is the
least sensitive (Figure 4-55).
Adjust the sensitivity of a controller function by doing the
following:
Main Hoist Function Sensitivity icon -
selected
Main Hoist Function Sensitivity icon - active
Auxiliary Function Sensitivity icon - not
selected
Auxiliary Hoist Function Sensitivity icon -
selected
Auxiliary Hoist Function Sensitivity icon -
active
Icon Description
FIGURE 4-55
Controller Position
Function
Speed
Sensitivity
Curve 1
Neutral
Max
Speed
Full
Travel
FIGURE 4-56
Function
Speed
Sensitivity
Curve 3
Sensitivity
Curve 1
Neutral
Max
Speed
Full
Travel
Controller Position
