eikon e2s Service and Repair Manual UL 106
Microwave Power test: Measuring the microwave power output of the magnetron(s)
Check that the following requirements have been met:
The appliance is cool.
NOTE:
The power output is established under IEC 705 standard method which is only workable in laboratory
controlled conditions. The power output is also affected by line voltage under load, so this test is an
approximation only.
1.
Enter Service Mode.
For details see "Checking the condition of your appliance".
2.
Select 'Visual View' to check the cavity temperature reading is as
close to 0°C as possible.
3.
Fill a microwave safe container (glass or plastic) with one litre
(1.78 pints) of tap water at 20°C (68°F).
4.
Measure and record the water temperature in the container using
a thermometer capable of reading ±0.1 degree increments.
5.
Place the container centrally into the cavity.
6.
Select ‘Microwave Power Test’ from the Service Mode tests
(microwave power 100% for 63 seconds, fan minimum).
