12 Replacing components
eikon e2s Service and Repair Manual UL 141
Component List
Item
Name
Function
1
Front panel
The front panel houses the touchscreen and the
QTS assembly.
2
Door handle
Open the oven door using the door handle. Never
use the door handle to lift the appliance.
3
Door cover panel
The door cover panel can be detached for accessing
the door hinge assembly.
4
Frame
The front, top, side and back panels of the casing
and the oven door are mounted to the metal frame.
5
Air filter faceplate
The faceplate can be tilted to access the air filter.
6
Foot
The oven rests on a high quality plastic foot ex-
tending over the whole length of the appliance.
7
Base plate
The metal base plate carries all oven components.
8
Back panel
The back panel shows a grille permitting ventilation
of the oven interior.
9
10
Cavity
The cavity (cooking chamber) for cooking food can
be accessed by opening the oven door.
11
Door hinge assembly
The door hinges interact with the microswitches /
interlocks.
12
Door microswitch(es) / interlock(s)
The microswitches / interlocks are connected to the
door hinges and switch off the magnetron(s) when
the oven door is opened.
13
Cooling fan
The cooling fan pulls air through the air filter into the
interior of the casing in order to cool the electrical
components.
14
Convection (hot air) fan motor speed controller
This component controls the speed of the convec-
tion fan motor depending on specific oven settings.
15
Transformer (high voltage) (2000W e2s variant: 2x)
A high voltage transformer feeds a magnetron.
16
Convection (hot air) fan motor
The convection fan motor is controlled by the speed
controller and drives the convection fan.
17
Exhaust pipe
The exhaust pipe leads excessive steam from the
cavity to the cooling duct and the rear air outlet of the
oven.
18
Cooling duct
The cooling duct leads heat generated by the
magnetron(s) to the rear of the oven.
19
Transformer (low voltage
- SRB) The low voltage transformer feeds the SRB.
20
Magnetron (high voltage) (2000W e2s variant: 2x)
A magnetron generates microwaves.
21
Waveguide (2000W e2s variant: 2x)
A waveguide leads microwaves from a magnetron
into the cavity.
22
Capacitor (high voltage) (2000W e2s variant: 2x)
The capacitor completes the magnetron circuit for
required high voltage.
23
Stirrer motor (2000W e2s variant: 2x)
A stirrer motor turns a stirrer distributing microwave
energy in the cavity.
24
Smart Relay Board (SRB)
The SRB controls all electrical oven components.
25
Loudspeaker
The loudspeaker produces sound signals (e.g.
cooking process completed) and can be deactivat-
ed.
26
Diode (high voltage) (2000W e2s variant: 2x)
The diode completes the magnetron circuit for
required high voltage.
