12 Replacing components
eikon e2s Service and Repair Manual UL 147
2.
Tilt the oven door to an angle of approx. 30° relative to the
ground.
3.
Remove the door assembly from the oven performing a rotational
movement of lifting the door up and pulling it away from the
casing.
4.
Unfasten two M5.5 hex head flange bolts next to the door hinges
to remove the cover panel from the door frame.
